CORiTEC 250i Loader PRO

5-axis machining meets automation in a compact design

The imes-icore CORiTEC 250i Loader PRO combines powerful 5-axis machining capabilities with automation to enable the highest levels of productivity for your lab or practice. Equipped with a 16-fold tool changer, a 7-fold blank changer, wet & dry capabilities, and 5-axis reach, the 250i loader PRO allows for hands-off production for even the most demanding metal applications.

The Proven 5-Axis System

The CORiTEC 250i Loader PRO milling machine is built on a proven and reliable dental milling platform from imes-icore. With automation integrated into the system, you can process PMMA, wax, zirconia, composites, peek, ain’t, glass ceramics, prefab abutments, chrome cobalt, and titanium with a highly productive workflow.

Get more information about the CORiTEC 250i series >



Automation Features

Blanker Changer/Loader

Available in 7 or 9 magazines





Tool Changer

16-fold tool changer with an interchangeable tool magazine





Auto-Calibration

Ensure precision and repeatability with auto-calibration



Highlights of the CORiTEC 250i series

Proto3000_IntegratedWaterSupplyandFiltration

Integrated water supply and filtration

250i / 250i dry

Proto3000_IntegratedTemperatureCompensation

Integrated temperature compensation

250i Series

Proto3000_Mono-BlockCastBody

Mono-block cast body

novel, closed mono block casting body
for stability and precision

250i Loader PRO

Adapter variety

Adapter variety

Standard holders, prefabricated
abutments and block grinding

250i / 250i dry

Proto3000_UpTo30AxisAdjustment

Up to ± 30°Axis adjustment

for a 5-axis machining system

250i Series

Proto3000_CompressedAirSupply

Compressed air supply

only 7 bar external compressed air required; 3-fold integrated ionizer

250i Loader PRO

CORiTEC 250i series Key Features

  • Integrated – 250i/250i Dry – Tool runtime/breakage control, cooling circuit for cooling lubricant, compressed air and coolant level monitoring
  • Machining – 250i/250i Dry – Of zirconium, PMMA, wax, plastics and grindable board materials
  • Precision – 250i series – High precision due to integrated temperature compensation
  • Machining – 250i series – 5-axis machining system with up to ± 30° axis orientation, processing of prefabricated abutments, wet and dry machining possible
  • Integrated – 250i Loader PRO – Novel, closed mono-block cast body for stability and precision, 6-fold blank changer, PC and touch display
  • Optional – 250i Loader PRO – No external compressed air required, Incl. ionizer available
  • Wet milling possible – optional with 250i/250i dry
  • Dry milling possible
  • 5-axis milling possible
  • 10 milling tools with 3 mm shaft diameter / 12 milling tools at 250i/250i dry
  • Temperature compensation
  • Simple operation via touch screen
  • Abutment
  • Milling of blocks possible
  • Automatic 6-fold tool changer – 250i/250i dry contains no loader
  • ION optional possible – 250i/250i dry contains no ION

CORiTEC 250i Loader PRO



The newest milling machine from imes-icore® offers maximum performance, several new features and is able to work fully automated. These characteristics guarantee that the CORiTEC 250i Loader PRO is the perfect system for processing blanks and blocks.

The compact 5-axis milling machine opens up a completely new machine segment. The CORiTEC 250i Loader PRO offers automation and 5-axis simultaneous machining of circular blanks and blocks in the smallest space and at an attractive price performance ratio.

The milling system is equipped with a fully automatic 16-fold tool magazine with 3 mm milling tools and an integrated touch-screen monitor, which facilitates an intuitive operation in conjunction with the new SmartControlTM software. The fully automatic 7-fold (optional 9-fold) blank changer offers the possibility to process all common materials of the dental industry, an automated production is therefore feasible.





The CORiTEC 250i Loader PRO is the perfect solution for more movement in the dental technology!



Materials

PMMA

Zirconia

PEEK

WAX

Composite

Sintered ZrO2

Glass ceramics

PreFab Abutments

Applications

*Zero point-clamping system available on 250i Loader PRO

Let us guide you on your digital transformation journey. Speak with a Dental 3D Printing and Milling Expert today

Get Started

CORiTEC 250i series Specifications

Dimensions (W x D x H) in mm
Dimensions (W x D x H) in mm
CORiTEC 250i/250i dry: 544 x 650 x 615 / CORiTEC 250i Loader PRO: 790 x 613 x 724 mm
Number of axes
Number of axes
5 (five)
Number of tool positions
Number of tool positions
CORiTEC 250i / 250i dry: 12 / CORiTEC 250i Loader PRO: 16
Pmax~ maximum spindle speed
Pmax~ maximum spindle speed
CORiTEC 250i/ 250i dry: 0.4 kW 60.000 rpm / CORiTEC 250i Loader PRO: 750 W 100.000 rpm
Drive motors
Drive motors
Microstep motors
Blank change / Number of blank holder
Blank change / Number of blank holder
CORiTEC 250i/250i dry: manual 1-fold blank holder / CORiTEC 250i Loader PRO: automatic up to 7 blank holder
Dry processing
Dry processing
Ideally suitable
Wet processing
Wet processing
Ideally suitable
Blank processing 98/98,5 mm
Blank processing 98/98,5 mm
Ideally suitable
Block processing (CAD / CAM blocks)
Block processing (CAD / CAM blocks)
Ideally suitable
Zirconium oxide / aluminium oxide
Zirconium oxide / aluminium oxide
Ideally suitable
PMMA / Resins / PEEK / Composite / Wax
PMMA / Resins / PEEK / Composite / Wax
Ideally suitable
Glass Ceramics / Hybrid Ceramics
Glass Ceramics / Hybrid Ceramics
Ideally suitable
Sintered metal
Sintered metal
Suitable
Chromium cobalt
Chromium cobalt
Prefab-abutments possible with adapter
Titanium
Titanium
Prefab-abutments possible with adapter
Copings / Crowns / Inlay / Onlay
Copings / Crowns / Inlay / Onlay
Ideally suitable
Bridges up to 3 items
Bridges up to 3 items
Ideally suitable
Bridges up to 14 items
Bridges up to 14 items
Ideally suitable
Telescopes
Telescopes
Suitable
Therapeutic splints (bite splints)
Therapeutic splints (bite splints)
Ideally suitable
Tooth models
Tooth models
Ideally suitable
Model cast
Model cast
Ideally suitable
Abutments on titanium adhesive basis
Abutments on titanium adhesive basis
Suitable
Prefabricated abutments of Ti /CoCr
Prefabricated abutments of Ti /CoCr
Suitable
One-piece abutments (Zr, resins)
One-piece abutments (Zr, resins)
Suitable
One-piece abutments (CoCr, titanium)
One-piece abutments (CoCr, titanium)
In preparation
Barr structures / one-piece abutment bridges on implants
Barr structures / one-piece abutment bridges on implants
Not available
